Custom PCB

What Are Custom PCBs?

A custom PCB is a circuit board designed and manufactured to meet unique specifications, including size, material, layer count, and special features.

Key Features of Custom PCBs

✔ Flexible design options – Shapes, cutouts, non-standard sizes
✔ Material customization – FR-4, Rogers, Flex, Ceramic, Metal-core
✔ Advanced layer stacks – 1 to 30+ layers, HDI (high-density interconnects)
✔ Specialized finishes – ENIG, Immersion Silver, HASL, OSP

Common Applications of Custom PCBs

• Industrial automation (high-power, rugged boards)

• Medical devices (flexible, biocompatible materials)

• Aerospace & defense (high-reliability, low-weight designs)

• IoT & wearables (miniaturized, compact layouts)

Why Go Custom Instead of Off-the-Shelf PCBs?

✔ Perfect fit for your application – No compromises on performance
✔ Optimized cost-efficiency – Only pay for the features you need
✔ Faster time-to-market – No redesigns for standard board limitations
✔ Higher reliability – Avoids excess components or unnecessary traces

When Should You Use Custom PCBs?

• Non-standard form factors (odd shapes, cutouts, thin-flex designs)

• High-frequency or high-power requirements (RF, power electronics)

• Special materials needed (thermal management, biocompatibility)

H2: From Design to Finished Boards – How It Works

• Design Submission – Upload Gerber, ODB++, or Eagle/Altium files

• DFM Review – Engineers optimize for cost & manufacturability

• Material Selection – Choose substrates, copper weight, finish

• Fabrication & Testing – Automated production + quality checks

• Shipping & Support – Fast global delivery with documentation

Tips for a Smooth Custom PCB Order

• Use clear layer naming in Gerber files


• Specify impedance requirements early

• Choose the right surface finish (ENIG for fine-pitch components)

•


H2: Custom Printed Circuit Boards for Every Need

• Specialty PCB Customizations

• Laser-drilled microvias (HDI designs)

• Embedded passives & actives (Space-saving electronics)

• High-voltage & RF-optimized (5G, RADAR, energy systems)

Quality Control for Custom PCBs

✔ Automated Optical Inspection (AOI) – Catches soldering & alignment defects
✔ Electrical Testing (Flying Probe/ICT) – Validates connectivity & performance
✔ Cross-Section Analysis – Ensures plating thickness & via integrity
✔ IPC-A-600 Class 2/3 Certification – Meets military/aerospace standards

Our Quality Guarantee

• No-defect warranty (X-ray inspection for BGA assemblies)


• Traceability reports (Material batch tracking)

Should You Use Custom or Off-the-Shelf Boards?
