IC Substrate PCB

As a critical bridge between silicon dies and standard PCBs, our IC Substrate (Package Substrate) manufacturing service provides the essential high-density interconnect platform for modern chip packaging. We specialize in producing ultra-fine line PCBs that meet the demanding electrical, thermal, and physical requirements of BGA, CSP, FC-CSP, SiP, and other advanced packages, enabling higher performance, miniaturization, and reliability for your semiconductor devices.

Core Capabilities & Technologies

High-Density Interconnect (HDI): Expertise in 2+N+2, 3+N+3, and any-layer HDI builds with laser microvias (as small as 50µm) to accommodate high I/O count and fine-pitch chips.
Ultra-Fine Line Tracing: Capable of trace/space down to 15µm/15µm, supporting the most demanding routing densities for leading-edge packaging.
Advanced Materials: Utilization of specialized substrates with tailored CTE (Coefficient of Thermal Expansion), such as BT (Bismaleimide Triazine), ABF (Ajinomoto Build-up Film), and low-loss high-frequency materials for optimal electrical and thermal performance.
Precise Surface Finishes: Offerings include ENEPIG (Electroless Nickel Electroless Palladium Immersion Gold), ENIG, and selective hard gold for reliable wire bonding and flip-chip interconnection.
Strict Process Control: Comprehensive control over impedance, dielectric thickness, and copper profile to ensure signal integrity and power delivery for high-speed semiconductor applications.

Key Features & Benefits

Minaturization Enabler: Supports the trend towards smaller, thinner, and more powerful electronic devices through superior packaging density.
Enhanced Electrical Performance: Optimized design and material selection minimize signal loss, power noise, and latency for high-speed chips (processors, FPGAs, ASICs).
Superior Thermal Management: Provides effective heat dissipation pathways from the chip to the motherboard, critical for device reliability and performance.
High Reliability: Rigorous testing for interconnect integrity, ensuring robustness under thermal cycling and mechanical stress typical in packaged environments.

Primary Applications

FC-BGA (Flip-Chip Ball Grid Array) substrates for CPUs, GPUs, and high-performance ASICs.
CSP (Chip Scale Package) and WLCSP (Wafer Level CSP) substrates.
SiP (System-in-Package) and PoP (Package-on-Package) interposers and substrates.
RF Module and Memory Module packaging.
Advanced packaging substrates for AI, 5G, automotive, and IoT semiconductors.

Your Partner in Advanced Packaging

From design consultation and rapid prototyping to volume production, we provide full-turnkey support for your IC substrate needs. Our vertically integrated control ensures stringent quality standards, confidentiality (NDA protection), and fast turnaround for this critical component in your semiconductor supply chain.
