SiP PCB

Our System-in-Package (SiP) PCB substrates provide the essential foundation for integrating multiple active chips, passive components, and sometimes MEMS or sensors into a single, compact, high-performance package. This advanced packaging solution enables significant space savings, enhanced electrical performance, and optimized system functionality, making it ideal for the most demanding applications where miniaturization and performance are paramount.

Core Features & Advantages

High-Density Integration: Engineered for fine line widths and fine pitch routing to accommodate the complex interconnections required when combining diverse components (processors, memory, RF, sensors) within a single package.
Advanced Via & Layer Architecture: Supports multiple via structures (microvias, stacked vias, filled vias) and high layer counts to ensure superior electrical performance, effective heat dissipation, and reliable power delivery for the integrated system.
Precision Manufacturing: Utilizes tight layer-to-layer alignment technology to guarantee the accuracy and reliability of intricate, multi-layered interconnects critical for SiP functionality.
Flexible Package & Finish Solutions: Offers a wide range of package solutions (BGA, LGA, Flip Chip, Hybrid) and surface finishes (Soft Au, ENEPIG, ENIG, SOP, OSP) to match specific assembly, bonding, and reliability requirements for different chips within the package.
Signal & Thermal Integrity: Provides impedance control for critical signal traces and is designed for enhanced thermal performance to manage heat effectively in densely packed, high-power systems.

Technical Specifications

Package Solutions: BGA, LGA, Flip Chip, Hybrid Integration, etc.
Surface Finishes: Soft Gold (Wire Bonding), ENEPIG, ENIG, SOP, OSP, and others.
Design Support: Impedance control for critical high-speed signals.
Key Performance: Enhanced thermal management solutions integrated into the substrate design.
Core Capability: High-density interconnects with fine lines/spaces, high layer counts, and advanced microvia structures.

Primary Applications

SiP technology is revolutionizing product design across industries by enabling smarter, smaller, and more capable devices:

Wearables & Mobile: Smartwatches, AR/VR glasses, ultra-compact modules.
RF & Communication: 5G/6G front-end modules (FEMs), RF transceivers, IoT modules.
Automotive: Advanced driver-assistance systems (ADAS) sensor fusion, infotainment controllers.
High-Performance Computing: Silicon photonics, AI accelerators, and memory-logic integration.

Your Partner in SiP Realization

From initial design consultation on substrate layout and thermal management to high-volume manufacturing, we offer full turnkey support. Leveraging our vertically integrated manufacturing and strict process control, we ensure your complex SiP substrate is delivered with the highest reliability, confidentiality (NDA protected), and speed.
