PTFE PCB

365 PCB specializes in PTFE PCB manufacturing for high-frequency applications — delivering superior signal integrity, minimal dielectric loss, and extreme thermal stability. Trusted by aerospace, 5G, and radar system engineers.

PTFE PCB Boards: The Gold Standard for RF/Microwave Applications

Key Points:

  • Ultra-low dielectric loss (Dk 2.0-2.2 @ 10GHz)

  • Exceptionally stable across temperature extremes (-200°C to +260°C)

  • Ideal for 5G, mmWave, radar, satellite, and aerospace systems

  • Available with Rogers, Taconic, or Arlon PTFE laminates


 Why PTFE is the Ultimate PCB Material for High-Frequency?

  • Near-Zero Signal Loss: Df as low as 0.0009 (vs FR4's 0.02)

  • Phase Stability: Minimal delay variation vs temperature/frequency

  • Chemical Inertness: Resists corrosion, moisture, and harsh environments

  • Controlled Dk: Tight tolerances (±0.04) for precise impedance matching


PTFE PCB Variations:

  • Pure PTFE (soft, needs special handling)

  • Woven glass-reinforced (improves dimensional stability)

  • Ceramic-filled (adjustable Dk/thermal performance)


PTFE PCB Construction Options & Capabilities

  • Laminates Available: Rogers RO3000®, RT/duroid®, Taconic TLY, Arlon 25N

  • Layers: 1-24 layers (multilayer PTFE requires special bonding)

  • Thickness: 0.004"-0.125" standard (custom upon request)

  • Copper Types: ED/RA foil, electrodeposited, or hybrid bonding

  • Surface Finishes: ENIG (recommended), immersion silver, gold plating


Special Features:

  • Embedded passive components

  • Via-in-pad & blind/buried vias

  • Laser ablation for ultra-fine features


Where Are PTFE Circuit Boards Used?

Aerospace/Defense:

  • Missile guidance systems

  • Phased array radar antennas

  • Telecom:5G massive MIMO antennas

Millimeter-wave backhaul links

  • Medical:MRI coil arrays

  • Hyperthermia treatment devices

  • Industrial:Plasma etchers

  • High-power RF amplifiers


Why PTFE Requires Specialized Fabrication?

  • Laser Drilling: For microvias (<100µm) due to PTFE's softness

  • Plasma Etching: Critical for proper via preparation & adhesion

  • Low-Temperature Lamination: Prevents material degradation

  • Strict Cleanroom Controls: Eliminates contaminants affecting RF performance



PTFE PCB FAQs

Q: Is PTFE PCB the same as "Teflon PCB"?

A: Yes — PTFE is the technical name, Teflon™ is DuPont's trademark.

Q: Why are PTFE PCBs more expensive than FR4?

A: Specialized materials, tighter tolerances, and advanced processes.

Q: Can PTFE boards be mixed with FR4 layers?

A: Yes (hybrid design), but requires careful RF transition planning.

Q: What's the best surface finish for PTFE RF boards?

A: ENIG (Ni/Au) for solderability and skin effect mitigation.
